Cables inside a tray must be organized and secured to prevent damage, sagging, or interference. Common connection methods for joining cable tray sections include splice plates, bolted connections, quick-connect systems, fish plates, clamps, and welding. Splice plates are flat metal plates bolted to the ends of two tray sections, providing strong, reliable connections suitable for straight runs. Quick-connect systems allow faster installation but may be limited to specific manufacturers .
Cables should be laid neatly, separated by voltage and function, and secured with cable ties or straps. Maintain proper spacing to avoid overheating and allow for expansion or future adjustments. Ladder trays typically use rung spacing of 6–9 inches to support cables, while solid or ventilated trays may require additional considerations for heat dissipation and electromagnetic interference . High-power and low-power cables should be separated to prevent EMI .
Metallic cable trays can serve as an Equipment Grounding Conductor (EGC) if they meet NEC requirements. Each tray section should be bonded using grounding clamps to maintain electrical continuity. If an EGC cable is installed, it should be mechanically anchored to prevent displacement under fault conditions. Avoid placing bare copper conductors in aluminum trays to prevent electrolytic corrosion; insulated conductors with proper bonding connections are recommended .
Follow NEC Article 392 for tray-rated cables, clearances, fill limits (40% for power cables, 50% for control cables), and prohibited areas such as hoistways. Ensure trays remain accessible for maintenance and are not permanently enclosed. Proper installation minimizes risks like overheating, fire, and mechanical failure while ensuring long-term reliability .
To ensure a safe and efficient cable tray system:
