How to secure cables in a ladder-style cable tray

Cables in a ladder-style cable tray should be secured using proper bundling, tie methods, and spacing to prevent sagging, maintain bend radius, and withstand mechanical forces.

Bundling and Tying Cables

Cables should be packed in bundles using appropriate banding or cable ties, ensuring the bundles are balanced at the center of the tray to distribute weight evenly and prevent excessive stress on the tray rungs or supports (BEAMA guide). Use non-metallic or metallic cable ties rated for the environment and temperature, and avoid over-tightening to prevent cable damage .

Spacing and Placement

• Rung spacing: Maintain a rung spacing of 6 to 9 inches (150–230 mm) for ladder trays to provide adequate support and prevent sagging, especially for heavy or large cables .
• Tie intervals: Secure cable bundles at regular intervals along the tray, typically every 24–36 inches, depending on cable weight and type.
• Separation of cable types: Keep power, control, and data cables separated to reduce electromagnetic interference and facilitate maintenance .

Maintaining Bend Radius

Ensure that cables do not exceed their minimum bend radius when entering or exiting the tray. Use tray edges or radius fittings to guide cables smoothly and prevent kinking or insulation damage .

Mechanical and Electrical Considerations

• The tray and cable supports must be strong enough to handle the weight of installed cables and any future additions .
• Cables should be secured to withstand forces generated during short circuits or other mechanical stresses .
• Ensure proper bonding and grounding of the tray system if it is used as an equipment grounding conductor, following NEC 392.60 requirements .

Best Practices

• Avoid cutting or drilling structural members without approval.
• Use compatible components designed and tested together as a system.
• For instrumentation or sensitive cables, consider additional protective measures such as solid covers or separate trays .
• Regularly inspect cable ties and bundles for wear, loosening, or damage, especially in industrial environments. By following these guidelines, cables in ladder-style trays will remain organized, mechanically secure, and electrically safe, while allowing for future maintenance and expansion.
