Wall-mounted electrical distribution box model

Wall-mounted electrical distribution boxes are available in a wide range of models from manufacturers like nVent HOFFMAN, CHINT, Legrand, and others, offering various sizes, materials, and protection ratings.

nVent HOFFMAN Models

nVent HOFFMAN offers the EPS and MAS series of wall-mounted enclosures suitable for indoor power distribution panels. Key features include:

• Material: Mild steel, pre-treated with iron phosphate and epoxy-polyester powder paint (RAL 7035)
• Widths: 600 mm and 800 mm
• Protection: IP66 (IEC 60529), IK10 (IEC 62262)
• Standards: UL508A, CSA 22.2, GOST, KEMA-KEUR
• Accessories: Modular system allows sub-sectioning, compatible with all EPS and general wall-mounted accessories
• Applications: Small power distribution panels, heavy-duty industrial use, flexible internal configurations

CHINT Final Distribution Boxes

CHINT provides modular final distribution boards with customizable options:

• Applications: Residential, commercial, and industrial environments
• Features: Additional circuit breakers, earth leakage protection, smart monitoring, remote control
• Design: Compact, space-saving, easy installation and maintenance
• Compliance: IEC-certified for safety and reliability
• Flexibility: Modular design allows adaptation and expansion to meet diverse electrical loads

Legrand Wall-Mounted Distribution Boxes

Legrand offers a variety of residential and small commercial panels:

• Material: Aluminum and copper options
• Current Ratings: 120 mm² up to 300 A, 300 mm² up to 540 A
• Applications: Energy distribution, protection, and management for small-scale installations

Other Industrial Models

Additional wall-mounted enclosures are available from brands like GEWISS, Bticino, and Drivia:

• Materials: Polyester reinforced with fiberglass, diecast aluminum, or metal
• Protection Ratings: IP65–IP68, IK10
• Sizes: Heights from 250 mm to 1,200 mm, depths up to 19 in
• Features: Hinged or swiveling doors, ventilation, EMC shielding, modular mounting plates, and accessories for automation and telecommunication applications

Summary

Wall-mounted electrical distribution boxes vary widely in material, size, protection rating, and modularity. Leading manufacturers include:

• nVent HOFFMAN: EPS and MAS series, steel, IP66/IK10
• CHINT: Modular final distribution boards, IEC-certified
• Legrand: Aluminum/copper panels for residential and small commercial use
• Other brands: GEWISS, Bticino, Drivia, offering fiberglass, aluminum, and high-IP enclosures These models cover applications from residential to heavy industrial, with options for modular expansion, smart monitoring, and high protection against environmental hazards.
