Cable tray installation bracket selection

Cable tray brackets should be installed using properly spaced supports, aligned cross members, and secure fasteners to ensure safe and stable cable management.

General Guidelines

1. Select the Appropriate Bracket Type Common bracket types include trapeze (swing) supports, center-hung supports, and wall-mounted brackets. The choice depends on the installation environment, tray type, and load requirements. Trapeze supports are widely used for ceiling installations, while center-hung supports allow easier cable placement from both sides .
2. Determine Support Spacing Proper spacing is critical to prevent sagging. Typical support spacing ranges from 1.5 to 3 meters, depending on tray type, material, and cable load. Maximum load per hanger is usually between 318 kg (700 lbs) and 340 kg (750 lbs) .
3. Prepare the Mounting Structure
   • For trapeze supports, thread a hex nut 25–50 mm above the tray bottom on the all-thread rod.
   • Slide on square washers and attach the cross member. Ensure vertical hangers pass through the cross member.
   • Drill or punch holes slightly larger than the all-thread diameter (1/16"–1/8") to allow easy adjustment .
4. Install the Cross Member and Tray Clips
   • Thread a second set of hex nuts to position the cross member snugly under the tray.
   • Ensure the cross member is level and allows horizontal adjustment for tray clips.
   • Tray clips (e.g., CG*-1) can be installed inside or outside the tray, depending on space and interference with rungs or connectors .
5. Align and Secure the Tray
   • Align trays straight and level.
   • Use connectors and fittings to join tray sections securely.
   • For long runs, consider using cable tray rollers to lay cables smoothly and avoid kinks .
6. Final Checks
   • Verify all clamps and brackets are tight.
   • Check for misalignment, overfilled sections, or unsupported spans.
   • Ensure grounding and bonding are properly installed for metal trays to maintain electrical safety .

Additional Considerations

• Load and Material: Choose brackets compatible with the tray material (steel, aluminum, or stainless steel) and environmental conditions to prevent corrosion or mechanical failure .
• Documentation: Maintain a layout plan and label all trays and cables for future maintenance and compliance with electrical codes .
• Safety: Only qualified personnel should perform installation, following local electrical codes and manufacturer guidelines . By following these steps, cable tray brackets can be installed safely, ensuring proper support, alignment, and long-term reliability of the cable management system.
